Welcome to Journal of Microelectronic Manufacturing!
2019
Volume 2, Issue 4
  • Published: Dec. 29, 2019
  • Supervised by:None
  • Hosted by:None
  • Published by:JoMM Editorial Office

Research Article top

Generative Learning in VLSI Design for Manufacturability: Current Status and Future Directions
Authors: Mohamed Baker Alawieh, Yibo Lin, Wei Ye et al.
Institution:Electrical and Computer Engineering, University of Texas at Austin, Austin
Keywords:Design for Manufacturability;Generative Learning;Machine Learning;Lithography
doi:10.33079/jomm.19020401
Issue 4: 19020401, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:3477
Abstract: With the continuous scaling of integrated circuit technologies, design for manufacturability (DFM) is becoming more critical, yet more challenging. Alongside, recent advances in machine learning ha...
A Photolithography Process Design for 5 nm Logic Process Flow
Authors: Qiang Wu, Yanli Li, Yushu Yang et al.
Institution:Shanghai IC R, &, D Center, 497, Gaosi Road, Zhangjiang Hi, -, Tech Park, China
Keywords:5 nm Logic Process;EUV;SADP;self-aligned LELE;RCWA;stochastics;mask 3D scattering
doi:10.33079/jomm.19020408
Issue 4: 19020408, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:7106
Abstract: With the introduction of EUV lithography, the photolithographic process in 5 nm logic process can be simplified to use mostly single exposure method. In a typical 5 nm logic process, the contact-po...
Dual Micro-power 150mA Ultra LDO CMOS Regulator with fast startup
Authors: Peng Zheng, Hai-Shi Wang
Institution:Chengdu University of Information Technology, Chengdu
Keywords:low dropout regulator (LDO);dual micro-power;ultra
doi:10.33079/jomm.19020402
Issue 4: 19020402, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:3178
Abstract: This paper presents a dual micro-power 150mA ultra LDO CMOS regulator, which is designed for high performance and small size portable wireless devices. The proposed LDO has been designed and simula...
Novel Pattern-Centric Solution for XtackingTM AFM Metrology
Authors: Sicong Wang, Jian Mi, Abhishek Vikram et al.
Institution:Yangtze Memory Technologies Co, ., Ltd, Wuhan
Keywords:VIA;Dishing;AFM;Image;Metrology;3D NAND
doi:10.33079/jomm.19020403
Issue 4: 19020403, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:2604
Abstract: 3D NAND (three-dimensional NAND type) has rapidly become the standard technology for enterprise flash memories, and is also gaining widespread use in other applications. Continued manufacturing pro...
Self-assembly of Blended PS-b-P2VP Block Copolymers
Authors: Baolin Zhang, Yu Chen, Shisheng Xiong
Institution:School of Information Science and Technology, Fudan University, Shanghai
Keywords:Micro-phase;blending;lamellar pattern;solvent annealing;sequential infiltration synthesis
doi:10.33079/jomm.19020404
Issue 4: 19020404, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:2377
Abstract: Directed Self-Assembly (DSA) of block copolymers (BCPs) is a promising technique for sub-10 nm nanofabrication, which is highly compatible with conventional lithography. DSA relies on the microphas...
The Effect of Fin Structure in 5 nm FinFET Technology
Authors: Enming Shang, Yu Ding, Wenqiao Chen et al.
Institution:Shanghai IC R, &, D Center, Shanghai
Keywords:5 nm;FinFET;fin profile;semiconductor
doi:10.33079/jomm.19020405
Issue 4: 19020405, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:3157
Abstract: In 5 nm technology node, FinFET device performance is sensitive to the dimension of the device structure such as the fin profile. In this work, we simulate the influence of fin height and fin width...
White Light Interference Solution for Novel 3D NAND VIA Dishing Metrology
Authors: Xiaoye Ding, Sicong Wang, Yi Zhou et al.
Institution:Yangtze Memory Technologies Co, ., Ltd, Wuhan
Keywords:WLI;Dishing;Metrology;3D NAND;Bonding
doi:10.33079/jomm.19020407
Issue 4: 19020407, 2019 | PDF
Research Article
Published: Dec. 25, 2019
Views:2345
Abstract: In traditional 3D NAND design, peripheral circuit accounts for 20-30% of the chip real-estate, which reduces the memory density of flash memory. As 3D NAND technology stacks to 128 layers or higher...
Current Status of the Integrated Circuit Industry in China Packaging and Testing Industry Review
Authors: Litho World
Keywords:Packaging;Testing Industry
doi:10.33079/jomm.19020409
Issue 4: 19020409, 2019 | PDF
Research Article
Published: Dec. 30, 2019
Views:2771
Abstract: China's IC industry has been flourishing in recent years, huge market demand together with government investments are the major driving forces for this development. The status and development momen...
